What Meshtastic is
Meshtastic is an open-source project that pairs inexpensive LoRa radio boards with a phone app. Messages hop from node to node, so a few well-placed nodes can link people across a neighbourhood or a valley.
- Range depends on terrain, antennas and settings, and there is no internet access or emergency service behind it.
- Frequencies and power limits follow local rules, so use the region setting that matches where you are.
A rough battery and panel estimate
| What are you sizing? | Worked example |
|---|---|
| Daily energy use | 6 Wh per dayThis is the example used here. Measure your own node to find its actual energy use. |
| Battery for 3 days without useful sun | 18 Wh + reserveThe radio needs 6 Wh × 3 days. Choose a protected battery pack with enough usable energy to cover this, losses and a reserve. |
| Example solar panel | 10 W → about 9 Wh per dayAssuming 1.5 equivalent full-sun hours per day and 60% of the panel’s rated output reaching the battery. |
| Energy left for recharging | About 3 Wh per day9 Wh produced − 6 Wh used. This is before any further losses: a flat reserve battery will not refill in one day. |
W describes power; Wh describes an amount of energy. These are example figures: weather, location and your node change the outcome.
Assumptions and calculation
This is our own example, not a figure from Meshtastic. Take 6 Wh a day and plan for three days without useful sun: the node then needs about 18 Wh delivered from the battery. Choose a protected battery pack whose usable energy, after its own losses and a reserve, clearly exceeds that, rather than counting on the nominal rating of individual cells.
For the panel, assume a winter day gives the equivalent of 1.5 hours of full sun and that 60% of the panel's rated output reaches the battery: 6 ÷ (1.5 × 0.6) ≈ 6.7 W just to cover one day's use. A 6 W panel would give only about 5.4 Wh, so a panel of around 10 W, about 9 Wh a day under the same assumptions, is a reasonable example with some margin. Covering daily use is not the same as quickly refilling a flat reserve battery, and your location and season can change these numbers, so measure your own node first.
Why one reading is not enough
A node spends most of its time listening and draws more power when it transmits. Most handheld multimeters show a momentary value, so a single reading can be far too low or too high.
- Meshtastic recommends a meter or bench supply that totals watt-hours or milliamp-hours over at least an hour, ideally two to six.
- Check that the meter can resolve very small currents.
- Do not test on a busy existing mesh: a different channel name or key does not stop your test from affecting others.
- Follow the official guide's instructions for a locally unused frequency slot within the permitted region setting.
From milliwatts to watt-hours
- Power is voltage times current: 5 V × 50 mA is 250 mW.
- Over 24 hours that becomes 6 Wh.
- In the guide's own example, a node used 0.72 Wh in three hours, an average of 240 mW, which works out at about 5.8 Wh a day.
Firmware update: check your version before upgrading
- On 8 October, Meshtastic withdrew 2.8.0 because of a packet-signing problem.
- The project asks anyone running 2.8.0 to move to 2.8.1; it also warns that 2.8.1 is alpha and most other users should wait.
- Back up your configuration before migrating from 2.7.
- Signed broadcasts from 2.8.0 and 2.8.1 are incompatible.
- This is a firmware warning, not a new energy measurement: the solar-sizing example below does not demonstrate better battery life after an update.
